New 2027 Ford E-450SD Base
- VIN: 1FDXE4FN9VDD13862
- Stock: VDD13862
New 2027 Ford E-450SD Base
VIN: 1FDXE4FN9VDD13862STOCK: VDD13862
Basic Info
-
Vin:1FDXE4FN9VDD13862
-
Stock Number:VDD13862
-
Exterior:White
-
Drivetrain:RWD
-
Interior:Medium Flint
-
Transmission:6-Speed Automatic
-
Engine:7.3L V8
Description
Vehicle Details
Exterior
- Wheels: 16" x 6" White Painted Steel
- Black Front Bumper w/Black Rub Strip/Fascia Accent
- Black Side Windows Trim and Black Front Windshield Trim
- Black Door Handles
- Light Tinted Glass
- Variable Intermittent Wipers
- Front Windshield -inc: Sun Visor Strip
- Fully Galvanized Steel Panels
- Black Grille
Interior
- 4-Way Driver Seat -inc: Manual Recline and Fore/Aft Movement
- 4-Way Passenger Seat -inc: Manual Recline and Fore/Aft Movement
- Manual Tilt/Telescoping Steering Column
- Gauges -inc: Speedometer, Odometer, Voltmeter, Oil Pressure, Engine Coolant Temp and Trip Odometer
- Front Cupholder
- Manual Air Conditioning
- Glove Box
- Front Vinyl Headliner
- Urethane Gear Shifter Material
- Partial Floor Console w/Storage and 2 12V DC Power Outlets
- Regular Dome Lighting
- Front Black Vinyl Floor Covering
- Tracker System
- Driver And Passenger Door Bins and 1st Row Underseat Storage
- Manual 1st Row Windows
- Driver Information Center
- Analog Appearance
- Fixed Front Head Restraints
- Driver And Front Passenger Armrests
- 2 12V DC Power Outlets
Entertainment
- 2 Speakers
- Fixed Antenna
Mechanical
- Engine: 7.3L V8 Port Fuel Injected Gasoline
- 4.56 Axle Ratio
- GVWR: 14,500 lb Payload Package
- 50 State Emission System
- Transmission w/Driver Selectable Mode and Oil Cooler
- Rear-Wheel Drive
- 78-Amp/Hr 750CCA Maintenance-Free Battery
- HD 210 Amp Alternator
- 8980# Maximum Payload
- HD Gas-Pressurized Shock Absorbers
- Front And Rear Anti-Roll Bars
- Hydraulic Power-Assist Steering
- Single Stainless Steel Exhaust
- 55 Gal. Fuel Tank
- Dual Rear Wheels
- Front Suspension w/Coil Springs
- Solid Axle Rear Suspension w/Leaf Springs
- 4-Wheel Disc Brakes w/4-Wheel ABS, Front Vented Discs and Hill Hold Control
Safety
- Side Impact Beams
- Collision Mitigation-Front
- Outboard Front Lap And Shoulder Safety Belts -inc: Height Adjusters and Pretensioners
Tech Specs
- Vehicle Name: Ford E-Series Cutaway
- Body Style: Chassis
- Body Code: H
- Drivetrain: Rear Wheel Drive
- Passenger Capacity: 2
- Base Curb Weight: 5431
- Gross Axle Wt Rating - Front: 5000
- Gross Axle Wt Rating - Rear: 9600
- Curb Weight - Front: 3048
- Curb Weight - Rear: 2383
- Gross Vehicle Weight Rating Cap: 14500
- Gross Combined Wt Rating: 22000
- Dead Weight Hitch - Max Trailer Wt.: 5000
- Dead Weight Hitch - Max Tongue Wt.: 500
- Wt Distributing Hitch - Max Trailer Wt.: 7500
- Wt Distributing Hitch - Max Tongue Wt.: 750
- Maximum Trailering Capacity: 7500
- Engine Order Code: 99N
- Engine Type: Regular Unleaded V-8
- Displacement: 7.3 L/445
- Fuel System: Sequential MPI
- SAE Net Horsepower @ RPM: 325 @ 3750
- SAE Net Torque @ RPM: 450 @ 3750
- Trans Order Code: 44P
- Trans Type: 6
- Trans Description Cont.: Automatic w/OD
- Trans Description Cont. Again:
- First Gear Ratio (:1): 3.97
- Second Gear Ratio (:1): 2.32
- Third Gear Ratio (:1): 1.52
- Fourth Gear Ratio (:1): 1.15
- Fifth Gear Ratio (:1): 0.86
- Sixth Gear Ratio (:1): 0.67
- Reverse Ratio (:1): 3.13
- Trans PTO Access: No
- Transfer Case Model: None
- Transfer Case Power Take Off: No
- Cold Cranking Amps @ 0° F (Primary): 750
- Cold Cranking Amps @ 0° F (2nd): 750
- Maximum Alternator Capacity (amps): 210
- Engine Oil Cooler: None
- Suspension Type - Front: Other
- Suspension Type - Rear: Leaf
- Spring Capacity - Front: 5000
- Spring Capacity - Rear: 9600
- Axle Type - Front: Independent
- Axle Type - Rear: Rigid Axle
- Axle Capacity - Front: 5000
- Axle Capacity - Rear: 9600
- Axle Ratio (:1) - Front: 4.56
- Axle Ratio (:1) - Rear: 4.56
- Front Tire Order Code: T68
- Rear Tire Order Code: T68
- Spare Tire Order Code:
- Front Tire Size: LT225/75SR16
- Rear Tire Size: LT225/75SR16
- Spare Tire Size:
- Front Tire Capacity: 5000
- Rear Tire Capacity: 9880
- Revolutions/Mile @ 45 mph - Front: 709
- Revolutions/Mile @ 45 mph - Rear: 709
- Front Wheel Size: 16 X 6
- Rear Wheel Size: 16 X 6
- Spare Wheel Size:
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material:
- Steering Type: Re-Circulating Ball
- Turning Diameter - Curb to Curb: 54.8
- Brake Type: 4-Wheel Disc
- Brake ABS System: 4-Wheel
- Brake ABS System (Second Line): 4-Wheel
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 13.6
- Rear Brake Rotor Diam x Thickness: 13.6
- Drum - Rear (Yes or ):
- Rear Drum Diam x Width:
- Fuel Tank Capacity, Approx: 55
- Front Head Room: 42
- Front Leg Room: 42.1
- Front Shoulder Room: 68.1
- Front Hip Room: 65.6
- Wheelbase: 158
- Length, Overall: 261.1
- Width, Max w/o mirrors: 79.4
- Height, Overall: 80
- Overhang, Rear w/o bumper: 68.5
- Cab to Axle: 100
- Cab to End of Frame: 168.5
- Ground to Top of Load Floor: 26
- Country of Origin: United States Ford Incomplete Vehicle
Details
- Driver Air Bag
- Passenger Air Bag
- A/C
- ABS
- 4-Wheel Disc Brakes
- Rear Wheel Drive
- Dual Rear Wheels
- 8 Cylinder Engine
- Gasoline Fuel
- Daytime Running Lights
- Bucket Seats
- Power Steering
- Adjustable Steering Wheel
- Tires - Front All-Season
- Tires - Rear All-Season
- Traction Control
- 6-Speed A/T
- Intermittent Wipers
- A/T
- Variable Speed Intermittent Wipers
- Automatic Headlights
- Steel Wheels
- Auxiliary Audio Input
- Front Collision Mitigation
